DIMENSIONS (cm)

Seat width: 30.48 - 33.02 - 35.56 - 38.10 - 40.64 - 43.18 - 45.72 - 48.26 - 50.80 cm

Seat depth: 30.48 - 33.02 - 35.56 - 38.10 - 40.64 - 43.18 - 45.72 - 48.26 - 50.80 cm

Front seat to floor height: 35.6 cm to 53.3 cm

Rear seat to floor height: 35.6 cm to 50.8 cm

Back height: 22.9 cm to 53.3 cm

Armrest height: 15.2 cm to 35.6 cm

Front frame angle: 70°, 75°, 80°, 85°, 90°

Back angle: 80° to 101°

Wheel camber: 0°, 2°, 4°, 6°, 8°

Center of gravity: 0 cm to 15.2 cm

Overall width: 47.6 cm min – 80 cm max.

TECHNICAL SPECIFICATIONS

Frame: Rigid

Material: T700 High-tensile strength carbon fiber

Transport Weight: 4.4 kg (without rear wheels, wheel locks, armrests, cushion and anti-tippers).

Lightest configuration: 7.8 kg (with wheel locks and wheels)

Weight Limit: 120 kg
