Seat Sizes: Seat Size 1, Seat Size 2 , Seat Size 3
Effective seat width (without upper leg supports) (cm): 26.5, 30, 35.5
Effective seat width (with upper leg supports) (cm): 18.5/22.5/26.5, 22/26/30, 27,5/31,5/33,5
Effective seat depth (cm): 24-30, 28.5-34.5, 33.5-42.5
Effective back width (without side supports) (cm): 30, 33.5, 39
Effective back width (with side supports) (cm): 14-24, 17-27, 22-32
Effective backrest height (cm): 37.5/41/44.5, 40.5/44.5/48.5, 45/50/55
Effective foot support to seat distance (cm): 22-28.5, 26-34.5, 30-40
Overall backrest height (cm): 42.5-49.5 , 47-55, 51.5-61.5
Overall folded height (cm): 22.5, 22.5, 22.5
Overall folded length (cm) 43, 49, 51.5
Overall folded width (cm) 36, 40, 45
Overall length (cm)L 36-37.5, 39.5-43, 43.5-49.5
Backrest recline angle (°): (-20)-(30), (-20)-(30), (-20)-(30)
Leg to seat surface angle (°): (-11)-(37), (-11)-(37), (-11)-(37)
Mass device (kg) : 5.2, 6.1, 7.5
Maximum rated load (kg): 42.2, 63.1, 79.5
Maximum user mass (kg): 35, 55, 70
Overall width (mm): 47, 51, 56
Overall length (cm): 76, 76, 76
Overall length with leg rest (cm): 93.5, 95.5, 111
Overall height (cm): 90.5-100, 95-105.5, 99.5-112
Overall height to pushbrace (cm): 85-102, 89-107, 93-113
Overall minimum turning diameter (cm): 85, 87.5, 90.5
Seat surface height at front edge (cm): 48-58, 48-58, 48-58
Seat plane angle (Seat tilt)(°): (-10°)-(30°), (-10°)-(30°), (-10°)-(30°)
Mass device (kg) : 5.2, 6.1, 7.5
Minimum distance that the device can be turned 180 degrees (cm): 85, 87.5 90.5
