Orthiopedic Reharunner 01
XRU034

Contact Us

Description

The RehaRunner01 treadmills range includes professional treadmills for rehabilitation use that are ideal for health care facilities and large physiotherapy units. Powered through the mains supply, they have a console that allows the following functions:

  • Speed and incline adjustment;
  • Liquid crystal display indicating heart rate, speed, time, distance and incline.

PROFILES:

  • 10 basic profile that can be modified by varying speed, incline and time separately;
  • 100 free profiles with the option to set time, tilt and speed for each of the 20 steps.

CARDIO:

Cardio exercise is a constant pulse rate training (until reaching 80% of one’s maximum theoretical heart rate), as the machine automatically adjusts the speed level so the heart beat remains within the set maximum heart rate.


FAT BURNING:
Fat burning exercise is a constant pulse training (until reaching 65% of one’s maximum theoretical heart rate) as the machine automatically adjusts the incline level so the heart beat remains within the set maximum heart rate.


FOUR TESTS:

Two auto tests – CHR (Constant Heart Rate) and CWL (Constant Work Level) – allow you to exercise at a constant heart rate and load. The third test, i.e. RUNNER TEST, allows you to exercise with an increasing load by stepping up the speed by 1 km/hper minute. The fourth test, i.e. COOPER TEST, allows you to exercise for 12 minutes and assess the maximum distance covered.

INDIVIDUAL DATA

Setting the user’s individual data (age and weight).

COUNT DOWN

Exercise program with decreasing workout duration.

Supplied with:

Fixed, side handrails
Large underarm support set with seat

Accessories

Small Walking Harness
01621
The walking harness provides support while exercising to improve gait. Size: Small - Thoracic circumference from 67 to 72 cm
Medium Walking Harness
01622
The walking harness provides support while exercising to improve gait. Size: Medium - Thoracic circumference from 73 to 105 cm
Large Walking Harness
01623
The walking harness provides support while exercising to improve gait. Size: Large - Thoracic circumference from 106 to 124 cm
Pelvic Sling
AC0285
Pelvic support
Ramp 1
XRU011
Ramp for XRU033 and XRU034 treadmills only.
Anti-Fall Support Reha 01
XRU012
Long handrails needed XRU029. For item code XRU033 or XRU034 only. Spreader bar included. Max. user's weight kg 150

Technical Spec.

Dimensions:
188 x 70 x 142 h cm
Walking deck:
140 x 48 cm
Weight:
145 kg
Max user weight:
150 kg
Max workout speed:
20.0 km/h
Console:
Touchscreen 10”
Min constant workout speed:
0.1 km/h
Max reverse motion speed:
0 - 5 km/h
Speed increments:
0.1 km/h
Incline:
From 0% to 22%
Emergency stop:
Button and pull-wire
Incline and speed change:
Electronic
Self-centering belt alignment system:
Yes
Self-lubricating belt system:
Yes
Isolation transformer:
1900 VA
Max peak motor:
5 HP (AC) / 2,5 HP
Fuji Inverter drive:
Yes
Power supply:
220/240 V - 50-60 Hz - 12 Amp
Incline auxiliary circuit supply:
18 V ac low voltage
Console auxiliary circuit supply:
12 V cc low voltage
Input power with motor running at max:
2400 VA
Rated input power:
1500 VA
Sound power:
< 30 dB
Audible tones:
When pressing keys
Shock absorbing table:
Yes
Serial interface with Trackmaster protocol:
Yes
Transport wheels:
Yes
Cardio rate machines already tested:
Delta Plus and Cube (Cardioline), Cardiette, Marquette (Sensormedic), Custo Med, Stress Manager (TBR), Tecnosoluzioni, Xcribe (Mortara Rangoni), SienaMedic, Visio Training, Esaote, Cortex
Output:
RS232
