Reharunner 02/51
XRU037

Contact Us

Description

The RehaRunner02 treadmills range includes professional treadmills for rehabilitation use that are ideal for health care facilities and large physiotherapy units. Powered through the mains supply, they have a console that allows the following functions:

  • Speed and incline adjustment;
  • Liquid crystal display indicating heart rate, speed, time, distance and incline;



PROFILES:

  • 10 basic profile that can be modified by varying speed, incline and time separately;
  • 100 free profiles with the option to set time, tilt and speed for each of the 20 steps;



CARDIO:

Cardio exercise is a constant pulse rate training (until reaching 80% of one’s maximum theoretical heart rate), as the machine automatically adjusts the speed level so the heart beat remains within the set maximum heart rate;


FAT BURNING:
Fat burning exercise is a constant pulse training (until reaching 65% of one’s maximum theoretical heart rate) as the machine automatically adjusts the incline level so the heart beat remains within the set maximum heart rate;


FOUR TESTS:

Two auto tests – CHR (Constant Heart Rate) and CWL (Constant Work Level) – allow you to exercise at a constant heart rate and load. The third test, i.e. RUNNER TEST, allows you to exercise with an increasing load by stepping up the speed by 1 km/hper minute. The fourth test, i.e. COOPER TEST, allows you to exercise for 12 minutes and assess the maximum distance covered.



INDIVIDUAL DATA

Setting the user’s individual data (age and weight);



COUNT DOWN

Exercise program with decreasing workout duration.



Dimensions: cm 210 x 80 x 150h
Walking deck: cm 154 x 51
Weight: kg 180
Max user weight: kg 220
Max workout speed: 25.0 km/h



Accessories

Small Walking Harness
01621
The walking harness provides support while exercising to improve gait. Size: Small - Thoracic circumference from 67 to 72 cm
Medium Walking Harness
01622
The walking harness provides support while exercising to improve gait. Size: Medium - Thoracic circumference from 73 to 105 cm
Large Walking Harness
01623
The walking harness provides support while exercising to improve gait. Size: Large - Thoracic circumference from 106 to 124 cm
Antebrachial Supports
AC0234
Height adjustable antebrachial supports (pair)
Padded Table With Recess
AC0235
Padded table with recess
Underarm Supports
AC0283
Height adjustable underarm supports (pair)
Ring-Shaped Chest Support
AC0284
Ring-shaped chest support
Pelvic Sling
AC0285
Pelvic support
Pelvic Support
AC0286
Pelvic support
Adjustable Handrails
XRU013
Height- and length-adjustable handrails
Transverse Handrail
XRU014
Transverse handrail
Fixed Handrails
XRU017
Fixed, prolonged handrails XRU015 e XRU016
Large Underarm Supports
XRU018
Height adjustable underarm supports
Anti-Fall Support Reha 02
XRU020
Long handrails needed XRU017. It can be fitted on treadmills XRU037 or XRU038 only. Spreader bar included. Max. user's weight kg 150
Lateral Sliding Seats
XRU021
Lateral sliding seats (pair)
Locking Devices
XRU023
Locking devices (pair)
Ramp 2
XRU030
120 cm long ramp for an assisted access to the treadmill XRU015

Technical Spec.

Console:
Touchscreen 10”
Min constant workout speed:
0.1 km/h
Max reverse motion speed:
0 - 5 km/h
Speed increments:
0.1 km/h
Incline:
From 0% to 30%
Emergency stop:
Button and pull-wire
Incline and speed change:
Electronic
Self-centering belt alignment system:
Yes
Self-lubricating belt system:
Yes
Isolation transformer:
1900 VA
Max peak motor:
7 HP (AC)
Fuji Inverter drive:
Yes
Power supply:
220/240 V - 50-60 Hz - 12 Amp
Incline auxiliary circuit supply:
18 V ac low voltage
Console auxiliary circuit supply:
12 V cc low voltage
Input power with motor running at max:
3000 VA
Rated input power:
2500 VA
Sound power:
< 30 dB
Audible tones:
When pressing keys
Shock absorbing table:
Yes
Serial interface with Trackmaster protocol:
Yes
Transport wheels:
Yes
Cardio rate machines already tested:
Delta Plus and Cube (Cardioline), Cardiette, Marquette (Sensormedic), Custo Med, Stress Manager (TBR), Tecnosoluzioni, Xcribe (Mortara Rangoni), SienaMedic, Visio Training, Esaote, Cortex
Output:
RS232

Video
